SPECIFICATIONS

Brand Name: MHPOWOS

Certification: CE,FCC,RoHS,pse,weee

Flexible Solar Panel: No

Foldable Solar Panel: Yes

Folded Size: 59.6cx54x4cm±0.5cm

High-concerned chemical: None

Material: Monocrystalline Silicon

Max. Power: 110W

Maximum Power Current(Imp): 5.5A Max

Maximum Power Voltage (Vmp): 20V

Model Number: MH-SP-001-BLA

Module Efficien: 24%

Net Weight: 3.07KG±0.3KG

Nominal Capacity: 59.6cx54x4cm

Number of Cells: 2

Number of Panels: 2

Open Circuit Voltage (Voc): 24.0V

Operating Temperature: -20°C~60°

Origin:

Peak Power: 110W±5%

Rigid Solar Panel: No

Short Circuit Current (loc): 6.0A

Solar energy conversion rate: 23.5%

Type: Solar Panel

Unfolded Size: 1080x596.x22mm±0.5cm

is_customized: Yes

MHPOWOS 110W 20V Portable Foldable Solar Panel

MonocrystallineHighly Efficiency and 18 Month Long Term Warranty:MHPOWOS 110W Solarpanel is made of industry-leading monocrystalline silicon with a conversion rate of 23.5 %.Quickly power up your devices such as power station,solar generator, computers, etc. anywhere, anytime.

Portable and Foldable:The Solarpanel is equipped with an adjustable stand.You can adjust it according to the angle of the sun in order to get the maximum output power.The solar panel weighs 3kg and folds up like a briefcase,making it very easy to carry. Great for Home improvement,outdoors or camping.

Waterproof and Dustproof:MHPOWOS portable solar panel is IP67 rated for waterproof and dust resistance.Solar panel is designed to withstand harsh environments for outdoor activities.

Higher Conversion and 20V huge Voltage:MHPOWOS 110W foldable monocrystalline solar panel has high conversion efficiency which is up to 23.5%.20V 110W foldable solar panel generates more energy and perform better than traditional solar panels in any weather.

Adjustable Kickstand:The carrying case can be used as a kickstand and you can maximize solar coverage by setting it at the right angle. This means you can charge the solar generator faster.

Installation Suggestion:Install the solar panel in the sunniest place possible, in a location that prevents accidental damage to the panel.Place the solar panel directly under the sun at an angle of 30-60 degrees to the ground.

Technical Parameters

System Configuration:Off-Grid,Solar Technology:Monocrystalline,Wattage:110W,

Open Circuit Voltage (Voc) : 24.0V,Short Circuit Current (loc) : 6.0A,

Maximum Power Voltage (Vmp) : 20V,Maximum Power Current(Imp) : 5.5A Max,

Solar energy conversion rate: 23.5%,Operating Temperature:  -20°C~60°,

All technical data under standard test conditions (STC: E=1000W/m2 TC=25CAM=1.5)

Dimension:Unfolded Size:1080x596x22mm/42.5x23.4x0.86inch,Folded Size: 59.6cx54x4cm/23.46x21.25x1.57 inch,Net Weight : 3.07KG/108.3oz

WHAT'S INCLUDED:1*110W Solar panel with MC4 connector cable,1*Instruction Manual
